| Conveyor medium* |
Steel accumulated chain(Default), plastic accumulated chain, Steel accumulated chain with cover, plastic accumulated chain with cover |
| Workpiece pallet width(mm)* |
160,240,320,400,480,560,640,800,1040,1200 |
| Conveyor length(mm)* |
500≤L≤15000 (Reversible operation possible for conveyor length ≤2000 mm and accumulated chain without cover) |
| Rated speed(m/min)* |
0,6,9,12,15,18 |
| Permitted maximum load(kg)* |
700 |
| Permitted maximum surface load* |
1.5kg/cm (with plastic glide profile), 2.0kg/cm(with steel glide profile) |
| Motor type* |
Three phase motor |
| Motor mounting location* |
L(left), R(Right), ML(Middle-Left), MR(middle-Right) |
| Motor mounting angle* |
0°,90°,180°,270° |
| Working voltage* |
220/380AC 50Hz |
| Working frequency* |
50Hz |
| Motor connection* |
단자함 |
