Pengangkat skru bola LP/S
Butiran
LP/P Pallet conveyor pneumatic lifter Specification:
- Lebar palet dalam arah pengangkutan /mm:t160, 240, 320, 400, 480, 640, 800 (160u2264Bwtu2264800)
- Panjang palet dalam arah pengangkutan /mm:t160, 240, 320, 400, 480, 640, 800 (160u2264Bwtu2264800)
- Beban maksimum dibenarkan /kg:30
- Stroke :Customized
- Pemandu angkat :cylinder
- magnatic switches:termasuk
- Lifting speed : 300mm/s
- Transfer drive :Stepper motor
- Nominal speed /(m/min):t6, 9, 12, 15, 18
- Input Voltage:t48VDC/3.8A
Manfaat utama:
- high performance-price ratio
- Stable and Easy to control
- Clean and Easy maintaining
- Modular design for quick installing
- Allowed reverse operating
- compact size for space saving
Applications:
