Aerial Conveyor Systems-3

ET2/B Pallet Transverse Unit

Transport medium Timing belt
Pallet width /mmBwt240,320,400,480,640 (or customized)
Pallet length /mmLwt240,320,400,480,640 (or customized)
Lifting drive φ50 Air cylinder
Transport drive Stepping motor
Motor Torque /(N-m) 9.4
VoltageU48VDC

BC2 Timing Belt Pallet Conveyor

Transfer medium Timing belt
Pallet width in transport direction /mmBwt160, 240, 320, 400, 480, 640, 800 (160≤Bwt≤800)
conveyor length /mmL300≤L≤6000
Extended length /mmLQ100≤LQ≤5700
Nominal speed /(m/min)V6, 9, 12, 15, 18
Max.Load /kg 60
Drive method 3 phase motor
Motor mounting methodMAL, R, M
Motor mounting direction 0°, 90°, 180°, 270°
VoltageU220/380 AC
Frequency /Hzf50
Motor connectionATTerminal box

Overhead Conveyor Lifter | Elevator

Core Components: Motor, Gear, Bearing, Gearbox

Lifting Drive Method: Servo Motor with Reducer

Lifting Distance: 900mm to 3000mm

Adapt Conveyor Type: Pallt Conveyor/Roller Conveyor

Aerial Conveying System

Aerial Conveying System is a kind of equipment and related supporting system used to realise the transportation of goods or materials in an aerial environment. It usually consists of a series of mechanical structures, such as conveyor belts, pallets, conveyor lifts, etc., as well as drives and control systems, and is capable of efficiently transferring goods from one location to another, especially in high-altitude areas that are difficult to reach by conventional ground transport.

Advantages

Efficient.Flexibility.Space-saving.High safety.

Application

Industrial field.Warehousing and logistics.Building construction.Airports and stations.
